Strong semi-automatic hydraulic pressure stamping machine video：
http://v.youku.com/v_show/id_XOTMwOTk4Mzk2.html
Technical parameters:
| 1 |
Price |
$4666 |
$3666 |
$2166 |
|
2
|
Type
|
TAM-320-H hydraulic pressure
|
TAM-320-1 Pneumatic
|
TAM-320 Pneumatic
|
|
3
|
Power
|
380V 50HZ
|
220V 50HZ
|
220V 50HZ
|
|
4
|
Heating power
|
3KW
|
2KW
|
1KW
|
|
5
|
Stamping area
|
460 * 260mm
|
460 * 260mm
|
320X180mm
|
|
6
|
Max product H
|
200MM
|
200MM
|
200~350MM
adjustable
|
|
7
|
Berth length
|
0-500mm roll
|
0-500mm roll
|
0-500mm roll
|
|
8
|
Temperature range
|
0-300 ℃
|
0-300 ℃
|
0-300 ℃
|
|
9
|
Foil paper bore
|
16-25mm
|
16-25mm
|
16-25mm
|
|
10
|
Working pressure
|
4Mpa
（about 2000~3000kg）
|
1500~2000Kg
|
500Kg
|
|
11
|
cylinder
|
|
160*130*130*50
|
100*130*130*50
|
|
12
|
Cylinder stroke
|
100mm
|
150mm
|
100mm
|
|
13
|
Dimensions
|
1050 * 1050 * 1950mm
|
1050*840*1910mm
|
820*710*1510mm
|
|
14
|
Weight
|
486kg
|
347kg
|
202.5kg
|
|
15
|
air compressor
|
|
2-3P
|
2-3P
|
|
16
|
gas storage capacity
|
|
60 liters
|
60 liters
|
| |
|
Wear-resistant hydraulic oil 46# 40kg，summer can use 68# |
|
|
appearance, convenient operation, high pressure, high degree of automation.
Advantages:
1 This series of stamping machine adopts hydraulic principles of design automation,
Send, receive paper with motor transmission,
Tape length can be arbitrarily controlled.
3 laminated stroke is high, suitable for larger thicker workpieces.
Product description:
1 pair of leather products, rubber products, technology products, plastic products, wood, paper and other surface bronzing, indentation, mark.
