Maquinas de serigrafia de gran tamano with Spring automatic peeling screen

Model No.︰

TMP-100130

Brand Name︰

tamprinter

Country of Origin︰

China

Unit Price︰

US $ 10000 / SET

Minimum Order︰

1 SET

Share on:

Product Description

1. Technical parameter:



Type

TMP-100130

Worktable area (mm)

1100X1400

Max printing area (mm)

1000X1300

Max screen fame size (mm)

1300X1600

Thickness of materials (mm)

20

Printing speed

400~900pcs/h

Air pressure (Mpa)

0.4~0.8

Air consumption (L/pcs)

13

Power

5KW

Max worktable height (mm)

880

Dimension (LXWXH)

2.38*1.95*1.6m

Weight

620kg

Rated voltage

380V/50Hz



TMP-100130  Spring automatic peeling screen Maquinas de serigrafia de gran tamano

video link:
http://youtu.be/d0zJxbDc-Js

big type printer with Automatic glitter powder spill machine test video

https://youtu.be/_efN9mhuo7Q

youku Video

http://v.youku.com/v_show/id_XNTUxOTc1OTgw.html

https://www.instagram.com/p/CJGR-3JrV8d/?igshid=165df0euae3yj

https://www.instagram.com/p/CJFX-mZr0X8/?igshid=4kej31g27o2k

https://www.instagram.com/p/CJFMWBVgubZ/?igshid=nhdmp8ow9lpc

https://www.instagram.com/p/CJFLwVig3mW/?igshid=1j2ix51wiiqqg

2. Application:

   This series of flat screen printing machine is widely used in electronics industry (such as PCB, thin-film switch and so on), packaging industry (such as cigarette case, wine box, gift box and so on), paper board industry (such as trademark, calendar, oil painting, computer keyboard, new year picture, transfer print paper, adhesive sticker, credit card, plate board and so on).

3. Features:

(1). High precision line and synchronous printing transmission adopts motor drive, speed equality and can be adjusted, balanced speed, speed adjustable.

(2). Oblique arm lifting motor, frequency control, the machine runs smoothly.

(3). Blade and back blade pressure regulating device, and can be adjusted to the thickness and size of printing.

(4). Vacuum adsorption fixed printing pieces.

(5). The printing plate has up and down, left and right, before and after tuning device, which makes it  works accurate and convenient on board.

(6). Equipped with a safety device so that the oblique arm is stopped in an upper position having a reliable security.

(7). Electronic control unit centralized control by the microcomputer controller, the whole operation more simple, flexible, and easy maintenance.



TAMPRINTER printers in the paper packaging industry operate in the following categories:
Bank card screen printing machine
Tobacco and Alcohol Gift Box UV Ink Automatic Screen Printing Machine
Picture album greeting card golden vermicelli printing machine production line

TAMPRINTER, a printing machinery for the sign and nameplate industry, operates the following categories:
Home appliance panel precision electric screen printing machine
Logo sign flip type screen printing machine
IMD precise screen printing machine
Blister injection T-slot screen printing machine
Instrument panel vacuum suction screen printing machine
Film button ultra-precision screen printing machine with automatic stacker

The operating categories of TAMPRINTER printing equipment in the electronic optics industry are as follows:
Light guide plate dust-free workshop screen printing machine
Mobile phone glass cover to prevent dripping oil screen printing machine
PCB green oil solder paste screen printing machine
FPC precision register screen printing machine
High-volume and rapid production of printers for electronic originals

TAMPRINTER's business categories in the apparel leather industry are as follows:
Mark mark automatic screen printing machine
Garment fabric roll-to-roll drying tunnel furnace
Luggage hot stamping machine
High-speed screen printing machine for shoe material

The business categories of TAMPRINTER in the transfer heat transfer industry are as follows:
Ceramic floral paper vertical screen printing machine with LED UV curing system
Wine label water transfer to prevent deformation low temperature ultraviolet ray dryer
Cycling decal and color screen printing machine with automatic stacker
Mark heat transfer infrared industrial tunnel furnace
Equipment transfer screen printing dryer

TAMPRINTER's business categories in the home improvement board industry are as follows:
Decorative glass large size flat screen printing machine
Integrated ceiling screen printing production line
Mupei building material varnish curing machine

TAMPRINTER's business categories in the sports equipment industry are as follows:
Bicycle decal continuous screen printing machine with drying production line
Cue Fishing Tackle Curved Screen Printing Machine
Fitness equipment pad printing hardware infrared oven
Outdoor supplies screen printing auxiliary equipment

Hot Tags: PAPER UV INK AUTO screen printing starter kit





Payment Terms︰ TT/LC/ Western Union

Product Image
